Productinformatie
Processor |
Type processor |
Ja |
Processorfabrikant |
Intel |
Processorfamilie |
Intel® Core™ i7 |
Processorgeneratie |
Intel® 12de generatie Core™ i7 |
Processormodel |
i7-12700 |
Maximale turbofrequentie van processor |
4,9 GHz |
Processor cache |
25 MB |
Thermal Design Power (TDP) |
65 W |
Geheugenbandbreedte ondersteund door de processor ( max) |
51,2 GB/s |
CPU configuratie (max) |
1 |
Geheugen |
Geheugen slots type |
SO-DIMM |
Aantal geheugenslots |
2 |
Aantal DIMM sloten |
2 |
Maximum intern geheugen |
64 GB |
Supported memory clock speeds |
3200 MHz |
Ondersteunde geheugen types |
DDR4-SDRAM |
Geheugen kanaal |
Dual-channel |
Geheugen bandbreedte (max) |
51,2 GB/s |
Geheugen voltage |
1.2,1.35 V |
Verwijderbare sleuf voor geheugenkaart |
SDXC with UHS-II support |
ECC |
Nee |
Non-ECC |
Ja |
Opslagmedia |
Ondersteunde types opslag-drives |
SSD |
Opslagschijf afmetingen ondersteund |
M.2 |
SSD-vormfactor |
M.2 |
Opslag schijf-interface |
PCI Express, SATA III |
Aantal storage drives ondersteund |
3 |
Soorten RAID |
0, 1 |
Geïntegreerde geheugenkaartlezer |
Ja |
Compatibele geheugenkaarten |
SDXC |
Geheugen |
Intern geheugentype |
DDR4-SDRAM |
Grafisch |
Ingebouwde grafische adapter |
Ja |
Grafische adapter-familie |
Intel |
On-board graphics adapter model |
Intel UHD Graphics 770 |
Aantal displays ondersteund |
3 |
Audio |
Ingebouwde luidsprekers |
Nee |
Netwerk |
Ethernet LAN |
Ja |
Wifi |
Ja |
Wifi-standaard |
Wi-Fi 6E (802.11ax) |
Wi-Fi-standaarden |
Wi-Fi 6E (802.11ax) |
WLAN-controller-model |
Intel Wi-Fi 6E AX211 |
Bluetooth |
Ja |
Bluetooth-versie |
5.2 |
Poorten & interfaces |
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A |
6 |
Aantal HDMI-poorten |
1 |
Mini HDMI ports kwantiteit |
0 |
HDMI versie |
2.0b |
VGA (D-Sub)poort(en) |
0 |
Aantal DisplayPorts |
0 |
Mini DisplayPort kwantiteit |
1 |
Aantal Ethernet LAN (RJ-45)-poorten |
1 |
Aantal SATA III connectors |
2 |
M.2 kaartslot (draadloos) |
Intel® Wi-Fi 6E AX211 |
USB-versie |
2.0/3.2 Gen 2 (3.1 Gen 2) |
Aantal USB-aansluitingen |
11 |
M.2-kaartsleuf (opslag) |
2 via PCH + 1 via CPU (NVMe) |
Aantal Thunderbolt 4-poorten |
2 |
Uitbreidingsmodules |
PCI Express slots versie |
5, 4.0 |
PCI Express x16 slots |
1 |
Design |
Type behuizing |
8L formaat PC |
Kleur van het product |
Zwart |
Type koeling |
Actief |
LED-indicatoren |
Ja |
Materiaal behuizing |
Metaal, Kunststof |
Bevestigingsmogelijkheid voor kabelslot |
Ja |
Kabelslot sleuf type |
Kensington |
Type product |
PC barebone |
Status |
Launched |
Prestatie |
Chipset moederbord |
Intel Z690 |
Aantal ondersteunde processoren |
1 |
BIOS type |
EEPROM |
Audio-uitgangskanalen |
7.1 kanalen |
Ondersteunt Windows |
Windows 11 x64, Windows 10 x64 |
Compatibele besturingssystemen |
Windows 10, 64-bit* |
Commodity Classification Automated Tracking System (CCATS) |
G157815L2 |
Export Control Classification Number (ECCN) |
5A992C |
Processor speciale functies |
Intel® vPro™ Platform Eligibility |
Nee |
Ingebouwde opties beschikbaar |
Nee |
Intel® Virtualization Technology (Intel® VT) |
VT-d, VT-x |
Intel® Rapid Storage Technology |
Ja |
Intel® AES New Instructions (Intel® AES-NI) |
Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) |
Ja |
Intel® VT-x with Extended Page Tables (EPT) |
Ja |
Intel® 64 |
Ja |
Idle States |
Ja |
Enhanced Intel SpeedStep Technology |
Ja |
Intel® Trusted Execution Technology |
Ja |
Execute Disable Bit |
Ja |
Intel® Stable Image Platform Program (SIPP) |
Ja |
Intel® Optane™ Memory Ready |
Ja |
Intel® Platform Trust Technology (Intel® PTT) |
Ja |
Intel® Virtualization Technology (VT-x) |
Ja |
Technische details |
Duurzaamheidscertificaten |
ENERGY STAR, ErP, REACH, RoHS |
Logistieke gegevens |
Code geharmoniseerd systeem (HS) |
84713000 |
Energie |
Soort voeding |
Interne voeding |
Eisen aan de omgeving |
Bedrijfstemperatuur (T-T) |
0 - 35 °C |
Temperatuur bij opslag |
-20 - 60 °C |
Gewicht en omvang |
Breedte |
357 mm |
Diepte |
189 mm |
Hoogte |
120 mm |
Inhoud van de verpakking |
Inclusief netsnoer |
Ja |
Overige specificaties |
Extra headers |
2x USB2.0, FRONT_PANEL |
Aantal SATA-aansluitingen |
2 |
Lanceringsdatum |
Q1'22 |
