Productinformatie
Kenmerken |
UPS-topologie |
Line-Interactive |
Output power capacity |
750 VA |
Uitgangsvermogen |
500 W |
Golfvorm |
Sinus |
Ingang operation voltage (min) |
151 V |
Ingang operation voltage (max) |
302 V |
Frequentie |
50/60 Hz |
Uitgang operation voltage (min) |
220 V |
Uitgang operation voltage (max) |
240 V |
Automatic Voltage Regulation (AVR) |
Ja |
Surge energy rating |
540 J |
Contacttijd (min) |
4 ms |
Contacttijd (max) |
8 ms |
Efficientie |
98 procent |
Geluidsniveau |
40 dB |
Spanningsbeveiliging |
Ja |
Geluidsalarm(en) |
Ja |
Auto-herstart |
Ja |
Poorten & interfaces |
Stopcontacttypes |
C13 stekker |
Stekker |
C14 stekker |
Aantal AC uitgangen |
6 AC-uitgang(en) |
Number of output IEC jumpers |
2 |
USB-poort |
Ja |
SmartSlot |
Ja |
Accu/Batterij |
Batterijtechnologie |
Sealed Lead Acid (VRLA) |
Batterij capaciteit |
146 VAh |
Typische backup tijd op volledige lading |
4,6 min |
Typische backup tijd op halve lading |
15,8 min |
Acculevensduur (max) |
5 jaar |
Accu/Batterij oplaadtijd |
3 uur |
Hot-swap batterij |
Ja |
Automatische batterij test |
Ja |
Koude start |
Ja |
Design |
Vormfactor |
Toren |
Kleur van het product |
Zwart |
Snoerlengte |
1,83 m |
LED-indicatoren |
Status |
Beeldscherm |
LCD |
RoHS compliance |
Ja |
Certificering |
CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH, PEP, EOLI |
Eisen aan de omgeving |
Bedrijfstemperatuur (T-T) |
0 - 40 °C |
Temperatuur bij opslag |
-15 - 45 °C |
Relatieve vochtigheid in bedrijf (V-V) |
5 - 95 procent |
Luchtvochtigheid bij opslag |
0 - 95 procent |
Hoogte, in bedrijf |
0 - 3000 m |
Hoogte bij opslag |
0 - 15000 m |
Gewicht en omvang |
Breedte |
138 mm |
Diepte |
358 mm |
Hoogte |
157 mm |
Gewicht |
13,2 kg |
Breedte verpakking |
278 mm |
Diepte verpakking |
499 mm |
Hoogte verpakking |
301 mm |
Gewicht verpakking |
14,2 kg |
Verpakking |
Meegeleverde kabels |
RS-232, USB-kabel |
Gebruikershandleiding |
Ja |
Snelle installatiehandleiding |
Ja |
Software-cd |
Ja |
Meegeleverde software |
Powershute Business Edition |
Logistieke gegevens |
Producten per pallet |
24 stuk(s) |
Overige specificaties |
Netspanning, in bedrijf |
230 V |
Nominale input voltage |
230 V |
