Productinformatie
Processor |
Processorfabrikant |
Intel |
Processor |
Processor socket |
(Intel) LGA 1151 |
Compatibele processors |
Intel® Celeron®, Intel® Core i3, Intel Core i5, Intel Core i7, Intel® Pentium® |
Max. aantal SMP-processoren |
1 |
Processor thermaal vermogen (max) |
91 W |
Geheugen |
Ondersteunde geheugen types |
DDR4-SDRAM |
Aantal geheugenslots |
2 |
Geheugen slots type |
DIMM |
Geheugen kanaal |
Dual |
Non-ECC |
Ja |
Supported memory clock speeds |
1866,2133,2400 MHz |
Maximum intern geheugen |
32 GB |
Ondersteunde geheugenmodule capaciteiten |
4GB,8GB,16GB |
Grafisch |
Ingebouwde grafische adapter |
Ja |
HDCP |
Ja |
DirectX versie |
12.0 |
Interne aansluitingen |
USB 2.0 aansluitingen |
2 |
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen |
1 |
Aantal SATA III connectors |
4 |
Aansluiting voor audiopaneel aan voorzijde |
Ja |
Voorpaneel-connector |
Ja |
ATX Power connector (24-pin) |
Ja |
Aansluiting voor CPU koeler |
Ja |
Peripheral (Molex) power connectors (4-pin) |
1 |
Aansluitingen achterzijde |
Aantal USB 2.0-poorten |
2 |
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A |
2 |
Aantal Ethernet LAN (RJ-45)-poorten |
1 |
PS/2 poort(en) |
1 |
VGA (D-Sub)poort(en) |
1 |
DVI-D poorten |
1 |
Netwerk |
Ethernet LAN |
Ja |
Ethernet interface type |
1 Gbit |
LAN controller |
Realtek RTL8111G |
Kenmerken |
Moederbord form factor |
Micro-ATX |
Moederbord chipset familie |
Intel |
Chipset moederbord |
Intel® H110 |
Audiochip |
Realtek ALC662 |
Audio-uitgangskanalen |
5.1 kanalen |
PC gezondheids monitor |
CPU, Ventilator, Temperatuur, Spanning |
Ondersteunt Windows |
Windows 10 Education x64,Windows 10 Enterprise x64,Windows 10 Home x64,Windows 10 Pro x64,Windows 7,Windows 8.1 Enterprise x64,Windows 8.1 Pro x64,Windows 8.1 x64 |
Uitbreidingsmodules |
PCI Express x1 (Gen 2.x) slots |
1 |
PCI Express x16 (Gen 3.x) slots |
1 |
Aantal M.2 (M) slots |
Geen |
BIOS |
BIOS type |
AMI |
Clear CMOS jumper |
Ja |
Gewicht en omvang |
Breedte |
215 mm |
Diepte |
170 mm |
Inhoud van de verpakking |
Meegeleverde kabels |
SATA |
Meegeleverde drivers |
Ja |
Meegeleverde software |
BullGuard, Smart Speed LAN |
Overige specificaties |
Snelle installatiehandleiding |
Ja |
