Productinformatie
Processor |
Type processor |
Ja |
Processorfamilie |
Intel Core i7-7xxx |
Processormodel |
i7-7567U |
Frequentie van processor |
3,5 GHz |
Aantal processorkernen |
2 |
Processor aantal threads |
4 |
Processor lithografie |
14 nm |
Maximale turbofrequentie van processor |
4 GHz |
L3 cache |
4 MB |
Thermal Design Power (TDP) |
28 W |
Geheugen |
Geheugen slots type |
SO-DIMM |
Aantal geheugenslots |
2 |
Maximum intern geheugen |
32 GB |
Supported memory clock speeds |
2133 MHz |
Ondersteunde geheugen types |
DDR4-SDRAM |
Geheugen kanaal |
Dual |
Geheugen bandbreedte (max) |
34,1 GB/s |
Geheugen voltage |
1.2 V |
ECC |
Nee |
Opslagmedia |
Ondersteunde types opslag-drives |
HDD, SSD |
Opslag schijf-interface |
M.2 PCIe x4 + SATA III 2.5" bay SATA III |
Aantal storage drives ondersteund |
2 |
Maximale opslagcapaciteit |
2 TB |
Soorten RAID |
0, 1 |
Geïntegreerde geheugenkaartlezer |
Ja |
Compatibele geheugenkaarten |
MicroSDXC |
Geheugen |
Intern geheugentype |
DDR4-SDRAM |
Grafisch |
Ingebouwde grafische adapter |
Ja |
Grafische adapter-familie |
Intel |
Grafische adapter |
Iris Plus Graphics 650 |
Maximum geheugen grafische adapter |
32000 MB |
Aantal displays ondersteund |
3 |
Netwerk |
Ethernet LAN |
Ja |
Wifi |
Ja |
Wi-Fi-standaarden |
IEEE 802.11ac |
LAN controller |
Intel I219-V |
Bluetooth |
Ja |
Bluetooth-versie |
4.2 |
Poorten & interfaces |
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A |
4 |
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C |
1 |
Aantal HDMI-poorten |
1 |
Mini HDMI ports kwantiteit |
0 |
HDMI versie |
2.0 |
VGA (D-Sub)poort(en) |
0 |
Aantal DisplayPorts |
1 (USB-C naar DP) |
Mini DisplayPort kwantiteit |
1 |
Combo koptelefoon/microfoon port |
Ja |
Hoeveelheid Thunderbolt ports |
1 |
Aantal SATA III connectors |
2 |
Uitbreidingsmodules |
PCI Express slots versie |
3.0 |
PCI Express x4 slots |
1 |
Design |
Kleur van het product |
Zwart |
Aan/uitschakelaar |
Ja |
LED-indicatoren |
Stroom |
VESA-montage |
Ja |
Type product |
Mini PC barebone |
ARK ID |
95065 |
Certificering |
ROHS, WEEE |
Prestatie |
Processor socket |
BGA 1356 |
BIOS type |
EEPROM |
Grootte BIOS-geheugen |
64 MB |
Trusted Platform Module (TPM) |
Nee |
Audio-uitgangskanalen |
7.1 kanalen |
Processor speciale functies |
Ingebouwde opties beschikbaar |
Nee |
Intel® Rapid Storage Technology |
Nee |
Intel® vPro™ Technology |
Nee |
Intel® AES New Instructions (Intel® AES-NI) |
Ja |
Intel® Quick Sync Video Technology |
Ja |
Intel® InTru™ 3D Technology |
Ja |
Intel® Clear Video HD Technology (Intel® CVT HD) |
Ja |
Intel® Turbo Boost Technology |
2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) |
Ja |
Intel® VT-x with Extended Page Tables (EPT) |
Ja |
Intel® 64 |
Ja |
Intel® My WiFi Technology (Intel® MWT) |
Ja |
Idle States |
Ja |
Enhanced Intel SpeedStep Technology |
Ja |
Thermal Monitoring Technologies |
Ja |
Intel® Flex Memory Access |
Ja |
Intel® Identity Protection Technology (Intel® IPT) |
Ja |
Intel® Trusted Execution Technology |
Nee |
Execute Disable Bit |
Ja |
Intel® Smart Cache |
Ja |
Intel® Visual BIOS |
Ja |
Intel® Express BIOS-update |
Ja |
Intel® TSX-NI |
Nee |
Intel® Secure Key |
Ja |
Intel® Smart Response Technology |
Ja |
Intel® Stable Image Platform Program (SIPP) |
Nee |
Intel® OS Guard |
Ja |
Intel® Clear Video-technologie |
Ja |
Energie |
Soort voeding |
Externe AC-adapter |
Netvoeding |
65 W |
AC-adapter, uitgangsspanning |
19 V |
Eisen aan de omgeving |
Bedrijfstemperatuur (T-T) |
0 - 40 °C |
Temperatuur bij opslag |
-20 - 60 °C |
Gewicht en omvang |
Breedte |
115 mm |
Diepte |
111 mm |
Hoogte |
51 mm |
Inhoud van de verpakking |
Inclusief AC-adapter |
Ja |
Snelstartgids |
Ja |
Overige specificaties |
Aantal SATA-aansluitingen |
1 |
